LQ121S1LG86

LQ121S1LG86

Download PDF Send Message

Basic Parameters

Panel Brand	Sharp	Panel Model	LQ121S1LG86
Panel Size	12.1 inches	Panel Type	a-Si TFT-LCD, Liquid Crystal Module
Resolution	800(RGB)x600, SVGA, 82PPI	Pixel Layout	RGB vertical stripe
Display Area	246(W)x184.5(H)mm	Appearance Size	276(W)x209(H)x9.6(D)mm
Viewable Area	249.0(W)x187.5(H)mm	Surface Treatment	Matt, Hard coating(3H)
Panel Brightness	1500 cd/m²(Typ.)	Contrast	800:1(Typ.)(TM)
Viewing Angle	80/80/80/60(Typ.)(CR≥10)	Operating Mode	TN, Normally White Display, Transmissive
Viewing Direction	6 o'clock	Response Time	30(Typ.)(Tr+Td) ms
Display Color	262K, 50% NTSC	Light Source Type	WLED, 50K hours, including LED driver
Operating Frequency	60Hz	Touch Screen	No Touch
Panel Weight	600g(Max.)	Panel Application	Industrial, Outdoor High Brightness
Signal Interface	LVDS(1 channel, 6-bit), 20 pins, terminal
Drive Screen Voltage	3.3V(Typ.)
Operating Environment	Operating: -30~70℃; Storage: -30~70℃

Related Products

Brand	Model Name	Size	Resolution	Brightness	Contrast Ratio	Backlight Type	Interface	pins	Operation Temperature	Download PDF	Add Inquiry
Tianma	P1210XGF1MA01	12.1"	1024×768	800 nits	1000:1	WLED	LVDS	20	-30~80 ° C
Tianma	P1210XGF1MA00	12.1"	1024×768	1300 nits	1000:1	WLED	LVDS	20	-30~80 ° C
Tianma	P1210WXF2MA00	12.1"	1280×800	1500 nits	1000:1	WLED	LVDS	20	-30~85 ° C
Tianma	P1210WXF2MA01	12.1"	1280×800	1100 nits	1000:1	WLED	LVDS	20	-30~80 °C
Innolux	G121ICE-PM1	12.1"	1280×800		1000:1	No Backlight	LVDS	30	-20~70 °C
Innolux	G121XCE-L01	12.1"	1024×768	600 nits	1000:1	WLED	LVDS	20	-30~85 ° C
Innolux	G121XCE-L02	12.1"	1024×768	500 nits	1000:1	WLED	LVDS	20	-30~70℃
Innolux	G121XCE-P01	12.1"	1024×768		1000:1	No Backlight	LVDS	20	-30~85 ° C
Sharp	LQ121S1LG88	12.1"	800×600	450 nits	800:1	WLED	LVDS	20	-15~70℃
AUO	G121EAN01.1	12.1"	1280×800	400 nits	1000:1	WLED	LVDS	30	-30~85℃
