Wide Operation Temperature, Ultra-high Brightness, White LED Backlight, Lifespan ≥ 50,000 hours, Front-mounted Terminals, and Matte surface
Brand
AUO
Type
a-Si TFT-LCD
Model
G190ETN01.8
Surface Finish
Matte, Hard coating (3H)
Size (inch)
19
Pixel Layout
RGB Vertical Strip
Outline Dimension (WxHxD mm)
396(W)×324(H)×11.7(D)
Operating Mode
TN
Active Area (WxH mm)
376.32(W)x301.056(H)
Backlight Type
WLED
Viewing Angle
85/85/80/80
Interface
LVDS, 30 pins
Resolution
1280x1024 (SXGA)
Response Time
7/3 (Typ.)(Tr/Td) ms
Brightness (cd/m²)
800
Dispay Colors
16.7M, 72%NTSC
Contrast Ratio
1000:1
Operating Temperature (°C )
-30~ 70
Operating Voltage
5V
Storage Temperature (°C )
-30 ~ 70
Operating Frequency
60Hz
Weight
1.8Kgs
Application
Industrial Control, Outdoor High Brightness Environment
✅12 Years of LCD Supply Chain Expertise
Since 2013, we’ve specialized in LCD distribution and customization, representing 7 top brands like AUO, TIANMA, and BOE. With over 100,000 panels in stock and 24/7 global shipping, our supply chain is rock-solid and reliable.
✅Backed by 7 International Certifications
ISO 9001/13485/14001, CE, RoHS, and IATF 16949 (in progress) — every shipment includes original test reports, ensuring zero export hurdles.
✅One-Stop Engineering Customization
Our 15-member expert team delivers prototypes in 7 days and mass production in 30. We support IP67 protection, -40~85℃ extreme temps, MIL-STD shock resistance, and sunlight-readable displays.
✅Proven by 3000+ Global Clients
Serving industry leaders like CRRC, Philips Healthcare, and BYD Automotive, we’ve delivered over 3 million flawless panels with zero returns and 95+ NPS satisfaction.
📩Request Full Free Quotation & Custom Solution Now → Email & WhatsApp & Wechat
1. What is the actual brightness of the G190ETN01.8? A: The rated brightness is 800 nits. It delivers exceptionally bright and clear display performance under indoor and semi-outdoor lighting conditions, making it ideal for digital signage, medical displays, self-service terminals, and other semi-outdoor or high-light environments.
2. Is this a wide-temperature display? A: Yes, it's an industrial-grade wide-temperature panel! Operating temperature range: -30°C to 70°C. Supports cold start at -30°C, achieving normal brightness within 10 seconds after power-on in sub-zero environments.
3. Does the surface have anti-glare or anti-reflective treatment? A: Standard configuration includes a 3H hardness AG anti-glare surface treatment + optical brightening film (DBEF). This effectively scatters ambient light, significantly reduces reflections, and ensures text remains clearly legible under strong light.
4. Does it support touch functionality? A: The base LCD display does not include touch screen, but it fully supports external capacitive/resistive touch screen.
5. Can it be made with a fully flat, bezel-less or ultra-narrow bezel design? A: Yes! Customizable seamless flat-panel designs are available for a more modern appearance, ideal for large-screen video walls, embedded installations, and high-end commercial display projects.
6. Can brightness automatically adjust based on ambient light? A: Optional ambient light sensor + auto-dimming functionality available. Indoors, brightness automatically reduces to 300-400 nits for power savings; outdoors, it automatically increases to 800 nits under strong sunlight. This protects eyes while ensuring optimal visibility for smarter usage.
7. Is the product certified? A: Certified with CE/RoHS. Features AUO factory-grade A-spec panels. Each unit undergoes 72-hour burn-in testing before shipment for stable, reliable quality. We offer a 1-year full-unit warranty + lifetime technical support. Free repair/replacement for non-human-induced damage.
