AT080TN64

Panel Brand	Chimei Innolux	Panel Model	AT080TN64
Panel Size	8.0 inches	Panel Type	a-Si TFT-LCD, liquid crystal module
Resolution	800(RGB)x480,WVGA,116PPI	Pixel Layout	RGB vertical stripe
Display Area	176.64(W)x99.36(H)mm	Appearance Size	192.8(W)x116.9(H)x6.7(D)mm
Visible Size	180.1(H)x103.4(V)mm	Surface Treatment	Matte
Display Brightness	500 cd/m²(Typ.)	Contrast	800:1(Typ.)(Transmission)
Viewing Direction	6 o'clock	Response Time	10/15(Typ.)(Tr/Td) ms
Viewing Angle	70/70/50/70(Typ.)(CR≥10)	Operation Mode	TN, Normally White Display, Transmission Type
Supported Colors	262K/16.2M, 50% NTSC	Light Source Type	WLED[3S12P], 20K hours, No Driver
Weight	245g(Typ.)	Applicable To	Automotive Display
Frame Rate	60Hz	Touch Panel	No Touch
Interface Type	50 pins Parallel RGB(1 channel, 6/8-bit), FPC
Voltage Supply	3.3/10.4/16.0/-7.0V(Typical)(DVDD/AVDD/VGH/VGL)
Application Environment	Operating temperature: -30~85℃; Storage temperature: -30~85℃
