♦ Size: 3.5 inch
♦ Available Brightness: 350~1200 nits
♦ Available Resolution: 320x240/320x480/480x640, etc. (customizable)
♦ Optional Touch Screen: Resistive Touch Screen(4-Wire/5-Wire)
Capacitive Touch Screen(I²C/USB/RS232), etc.
♦ Bonding Method: Optional Bonding Technology
(Air Bonding (Frame Bonding) / Full Bonding)
A 3.5-inch LCD touch screen integrates an LCD panel and a touch panel via gasket bonding or full lamination. Our company selects mature and reliable LCD panels and touch panels. We can provide corresponding products in accordance with customer requirements, and offer customization services for both LCD panels and touch panels. If you have any demands, please contact our staff through the contact information provided on our website for quotations, product inquiries, and specification requests.There is a table listing of our 3.5-inch industrial display kits with resistive/capacitive touch solution for your selection and reference.
Table 1---3.5 inch Industrial Display kits with Resistive / Capacitive touch Solution
TFT LCD Display
Touch Screen
Model
Brand
Brightness (nit)
Resolution
Interface
Active Area
Operating Temperature
Resistive Touch Screen
Capacitive Touch Screen
4-wire
5-wire
I2C
USB
RS232
ZJ035BF-01C
Innolux
450
320×240
Parallel/Serial
70.08(W)×52.56(H) mm
-30 ~ 80 °C
√
Customizable
TM035KDGP01-00
Tianma
350
TTL
-20 ~ 70 °C
TM035WDHG03
480×640
53.28(W)×71.04(H) mm
TM035PVGP01-00
600
320×480
CPU
48.96(W)×73.44(H) mm
AV035LQM-N10-28P0
BOE
750
-30 ~ 85 °C
TCG035QVLAAANN-AN00
Kyocera
70.56(W)×52.92(H) mm
TG035QVLQAANN-GN00
1200
TCG035QVLPDANN-GN50-S
1000
HXD035WP700
HXD
700
RGB
Touch screen bonding is a core process of industrial display kits, directly determining the product's touch accuracy, display performance, environmental adaptability and service life. Our LCD panel and touch screen bonding process is carried out in the factory's dust-free workshop, ensuring the high reliability of industrial-grade products. The dust-free workshop features constant temperature and humidity control, eliminating the impact of dust and impurities on lamination precision, with operators following standardized operating procedures throughout the entire process.After touch screen lamination, customers enjoy an upgraded display experience: improved light transmittance, reduced reflection, and better visibility in high-glare environments. Meanwhile, it enhances industrial-grade reliability with excellent vibration resistance, impact resistance, dustproof and waterproof performance, making it suitable for complex scenarios such as industrial equipment, vehicle-mounted systems and outdoor applications. We can customize lamination solutions according to customer needs, compatible with industrial display kits of various sizes and different touch types. Feel free to contact us for consultation if you have any requirements.
Q1: What are the key differences between resistive and capacitive touch options for the 3.5-inch industrial display kit? Which one should I choose?
A: Resistive touch screen offers precise operation with fingers, gloves, or styluses, ideal for harsh industrial environments due to its durability and low cost. Capacitive touch screen supports 5/10-point multi-touch, delivers faster response and smoother operation, suitable for interactive scenarios like industrial control panels or vehicle-mounted systems requiring frequent touch input. Choose based on your operating environment and interaction needs.
Q2: What is the brightness range for your 3.5-inch Industrial Display Kit?
A: Our 3.5-inch industrial display kits cover a brightness range of 350-1200 nits. The 1200-nit model is optimized for high-sunlight outdoor environments, meeting extreme brightness visibility demands. If you have specific brightness requirements, contact our sales managers and technical team for a professionally customized industrial display kit tailored to your needs!
Q3: What is the operating temperature range of this 3.5-inch industrial display kit?
A: The standard model features a wide operating temperature range of -20°C to 70°C, and we offer an extended temperature version (-30°C to 85°C) for extreme conditions. With industrial-grade components and anti-vibration design, it can stably operate in high-temperature workshops, cold outdoor facilities, or vehicle-mounted scenarios, meeting the reliability requirements of industrial control, marine navigation, and other harsh applications.
Q4: What are the interface of the 3.5-inch industrial display kits?
A: Most models use TTL interfaces and RGB interfaces, compatible with traditional hardware like industrial equipment and outdoor terminals.
Q5: Can you provide technical support and warranty?
A: We provide comprehensive technical support and reliable warranty service. All standard 3.5-inch industrial display kits enjoy a 12-month warranty, covering non-human induced quality defects. We offer free technical manuals, interface diagrams and driver guidance. Our technical team will respond to your inquiries promptly.
