♦ Brand: HIGGSTEC
♦ Model: T173S-5RB001N-0A18R0-200FH
♦ MOQ: 1 pcs
♦ Sample: Paid Sample
♦ Payment Method: T/T, Paypal, Cash, Alipay, Wechat
♦ Product Description: HIGGSTEC 17.3" 5-wire resistive touch screen, industrial grade with -10°C to +70°C operating temperature, 80% transparency, and 10 million actuation durability. Ideal for industrial HMI, military devices, medical devices, and kiosk applications.
♦ Important parameters of T173S-5RB001N-0A18R0-200FH:
381.90±0.20 × 214.80±0.20 mm
397.60±0.30 × 232.30±0.30 ×
2.20±0.20 mm
3H Pencil, Pressure 750g/45°
HIGGSTEC T173S-5RB001N-0A18R0-200FH is a 17.3-inch five-wire analog resistive touch panel screen designed for applications requiring high reliability and long lifespan, such as industrial HMI control devices, military display equipment, rail transit display equipment, aviation display equipment, medical display equipment, ad billboard displays, and self-service terminals. With an operating temperature range of -10°C to +70°C and storage from -40°C to +80°C, this resisive touch screen performs reliably in cold outdoor or hot factory environments. It has passed the test about 50 cycles of thermal shock testing (-40°C to 70°C). So you can trust the realiability of the 17.3 inch resistive touch panel screen.
✅️In stock & ready to ship. Best price available. Request a quote now!
Category
Analog Resistive Touch Screen
Safety Approvals
CE, RoHS, UL
Brand
HIGGSTEC
Aspect Ratio
16:9 (Width:Height)
Model
T173S-5RB001N-0A18R0-200FH
Active Area
381.9 × 214.8 mm
Screen Size
17.3 inch
Viewable Area
384.90 × 217.80 mm
Tag
5-Wire Analog Resistive Touch Panel
Outline Dimension
397.6 × 232.3 mm
Standard
Standard Off-the-Shelf Product
Overall Thickness
2.2 mm
Construction
Film / Glass
Surface Hardness
Hard coating (3H)
Touch Type
Single Touch
Simultaneous Touch Points
Tail Position
6 o'clock
Touch Mode
Point Touch
Tail Length
205 mm
Controller Type
External (Separate)
Transmittance
80%±3%
Controller Interface
USB, RS232
Operating Temperature
-10 ~ +70 °C
Storage Temperature
-40 ~ +80 °C
Key Description
HIGGSTEC 17.3" 5-Wire Resistive Touch Screen F+G Industrial / Medical / Military Grade
a. Excellent Durability During production, T173S-5RB001N-0A18R0-200FH undergoes a high-temperature sintering process at 485°C to 535°C. This step bonds the silver circuits firmly into the ITO glass. As a result, the silver traces will not easily separate even when temperatures change dramatically. This delivers a long-lasting product with excellent stability. Therefore, this touch screen is well suited for industrial control, military and aerospace applications, as well as other environments with high heat and humidity.
b. Wide Compatibility
The 17.3-inch 5-wire resistive touch panel responds to nearly any type of touch. You can use a bare finger, a gloved hand, a stylus pen, or even a hard object. Unlike capacitive screens that need bare skin or special conductive tools, this panel places no limits on how you interact with it. This makes it a flexible choice for diverse work environments, from clean indoor offices to dusty factory floors, from medical rooms to outdoor kiosks. If you need a touch panel that simply works with whatever you have in hand, this 5-wire resistive touch panel gets it.
c. Strong Anti-Interference Capability The 17.3 inch 5-wire resistive touch screen offers strong resistance to electromagnetic interference (EMI). In environments with heavy electrical noise—such as factory floors with large motors, medical rooms near imaging equipment, or communication stations—capacitive screens can malfunction or become unresponsive. This 5-wire resistive panel handles those conditions with ease. It delivers consistent touch performance without false triggers or signal loss caused by surrounding electrical activity. For applications where electrical noise is unavoidable, this touch screen provides a stable and dependable solution.
Zhengzhou Hengxinda Technology Co., Ltd. is a supplier focused on industrial-grade LCD displays, capacitive touch screens, resistive touch screens, infrared touch screens, LCD controller boards and industrial TFT LCD display solutions. We distribute well-known brands like AUO, Innolux, Sharp, IVO and BOE. Our products are widely used in industrial controls, medical equipment, automotive displays, outdoor terminals, and more. We provide one-stop shopping service, from product selection and sample testing to mass production. For touch screen service, we provide touch panel + LCD panel bonding technology.
Our clients have successfully evaluated the following applications:
• Industrial HMI Panels → Factory automation equipment, PLC operator panels, production line monitoring systems,data display machine • Self-service Terminal Equipment → Vending machines, ticketing terminals, information kiosks • Medical Display Equipment → Patient monitors, portable diagnostic equipment
✅️Need a customized touch panel solution? We make it happen. Contact us now!
Q1: Is this resistive touch screen a 5-wire or a 4-wire type? A: It's a 5-wire analog resistive touch screen, which is more durable and has more stable accuracy than a 4-wire one, making it suitable for high-frequency use.
Q2: Does it support operation with gloves?
A: Yes. Resistive touch screens rely on pressure sensing, so you can operate with gloves or a stylus.
Q3: How do I buy resistive touch screens?
A: You can fill in your information in the form below or contact us via the navigation bar on the right. We can provide you with the best price, free technical specifications, and customized touch display solutions.
Q4: What LCD controller board is required for this 17.3 inch 5-wire resistive touch screen? A: A 5-wire resistive LCD controller board is required. We can provide compatible LCD controller boards; please contact our sales manager for details and custom display solutions.
Q5: What is the warranty period? A: One-year warranty, but damage caused by human error, improper installation, or unauthorized disassembly is not covered.
