10.4" Five-Wire Analog Resistive Touch Panel T104S-5RB006N-0A18R0-080FH

Download PDF Send Message

♦ Brand: HIGGSTEC

♦ Model: T104S-5RB006N-0A18R0-080FH

♦ MOQ: 1 pcs

♦ Key Technologies:

• High-temperature process

• Bonding technology

• Narrow bezel design

♦ Sample: Paid Sample

♦ Payment Method: T/T, Paypal, Cash, Alipay, Wechat

10.4" Five-Wire Analog Resistive Touch Panel T104S-5RB006N-0A18R0-080FH| Wide Temp -10℃~+70℃ | 80% Transparency | Single tap life: 10,000,000 times actuations

I. Introduction to Five-Wire Resistive Touch Panel T104S-5RB006N-0A18R0-080FH

◊ Product Overview:

T104S-5RB006N-0A18R0-080FH is a 10.4-inch 5-wire high-temperature analog resistive touch panel, a premium industrial-grade touch screen within the 5-wire resistive products. In addition to the fundamental advantages of 5-wire resistive technology, T104S-5RB006N-0A18R0-080FH with single-tap life of 10,000,000 times actuations also offers exceptional resistance to high temperature & high humidity, scratch resistance, and no film expansion. With an extended market warranty period, this touch panel is ideally suited forindustrial control, military/aerospace, and other high-reliability applications where product quality is critical. T104S-5RB006N-0A18R0-080FH supports input via stylus or finger, features wide operating temperature capability, and delivers high durability.

◊ Here are important parameters of 10.4" Five-Wire Analog Resistive Touch Panel T104S-5RB006N-0A18R0-080FH:

Haze	8%±3%	Transparency	80%±3%
Active Area	211.58 × 158.75 mm	Outline Dimension	228.7 × 173.4 mm
Touch Stack-up	FG(ITO FILM+ITO GLASS)	Aspect Ratio	4:3 (W:H)
Linearity	X≤1.5%, Y≤1.5%	Knock Test	10,000,000 times
Operation Temperature	-10 ~ +70 °C	Storage Temperature	-40 ~ +80 °C
Hardness	3H Pencil,Pressure 750g/45°	Operating Force	Stylus=R0.8 ≦ 50g

II. Detailed Parameters of 10.4" Five-Wire Analog Resistive Touch Panel T104S-5RB006N-0A18R0-080FH

Category	Touch Screen & Controller > Analog Resistive Touch Screen	Safety Approvals	CE (Europe), RoHS (EU), UL (United States)
Brand	HIGGSTEC	Aspect Ratio	4:3 (Width:Height)
Model	T104S-5RB006N-0A18R0-080FH	Active Area	211.58 × 158.75 mm
Screen Size	10.4 inch	Viewable Area	215.58 × 162.75 mm
Tag	5-Wire Resistive Touch Screen	Outline Dimension	228.7 × 173.4 mm
Standard	Standard Off-the-Shelf Product	Overall Thickness	2.2 mm
Construction	Film / Glass	Surface Hardness	Hard coating (3H)
Touch Type	Single Touch	Simultaneous Touch Points	Single Touch
Tail Position	9 o'clock	Touch Mode	Point Touch
Tail Length	85 mm	Controller Type	External (Separate)
Transmittance	80% ± 3%	Controller Interface	USB, RS232
Operating Temperature	-10 ~ +70 °C	Storage Temperature	-40 ~ +80 °C
Key Description		HIGGSTEC 10.4" Wide Temperature 5-Wire Resistive Touch Screen F+G Industrial / Medical / Military Grade

III. Product Features

a. Excellent Durability
The high-temperature process of the T104S-5RB006N-0A18R0-080FH involves sintering the ITO glass printed with silver circuits at 485°C to 535°C. During this process, the silver lines and ITO glass penetrate and bond tightly with each other. As a result, even under significant temperature fluctuations, the silver circuits do not easily detach. This ensures long product life and high stability, making it suitable for industrial control, military/aerospace, and other environments with high temperature and high humidity.

b. Wide Compatibility

Resistive touch panels can recognize any form of touch input, such as fingers (with or without gloves), stylus pens, or other hard objects, allowing them to operate normally in various environments.

c. Strong Anti-Interference Capability
Resistive touch panels are highly immune to EMI, making them a reliable choice for electrically noisy environments.

About Zhengzhou Hengxinda Technology Co., Ltd

Zhengzhou Hengxinda Technology Co., Ltd. is a supplier focused on industrial-grade LCD displays, capacitive touch screens, resistive touch screen, infrared touch screen, LCD controller board and industrial TFT LCD display solutions. We distribute well-known brands like AUO, Innolux, Sharp, IVO and BOE. Our products are widely used in industrial controls, medical equipment, automotive displays, outdoor terminals, and more. We provide one-stop shopping service, from product selection and sample testing to mass production. For touch screen service, we provide touch panel + LCD panel bonding technology.
